The vibrating wire tri-axial joint meter is used to monitor movement of joints of structure in three orthogonal directions. It is suitable for installation in dam gallery.

APPLICATIONS
The typical application of tri-axial joint meter is monitoring of movement at constructions joints in concrete dam, tunnels and tanks or masonary structures.

FEATURES
→ Quick and easy installation
→ Excellent long term stability
→ Ease in automation
→ No effect of cable length on signal transmission

SPECIFICATIONS
Sensor Type - Vibrating wire
Range - 0-50mm and 100mm
Resolution - 0.1mm
Accuracy - ±0.25% FSR
Operating Temp. - -20℃ ~ 80℃
Ingres Protection - Confirms IP 65
Sensor Material - Stainless steel
